2500L/H Reverse Osmosis System for garden watering
Basics ofsystemDesign:
Raw water:well water
Treated water: forgarden watering
Power supply:3PH x400V, 50Hz
Process flow:Feed water tank →Feed water pump →Quarts sand
filter→Antiscalant dosing device→Micron Security
filter→high-pressure pump→RO→ Product tank→use point
ROplantdetailed info:
NO.
Items
Specification
unit
Remarks
1
Feed water tank
Material: PE/SUS 1
Capacity: 3m³
Liquid level controller(Lipu) 1
1 set
user prepare
2
Feed water pump
CHL8-40/1.5KW
Material:SS304
Voltage:3PH 400V/50Hz
Accessories: base, regulating valve, check valve, etc.
1 set
CNP
3
Quarts sand filter
Dimension: Φ600×1900(mm)
Material:FRP
Auto Control valve: F67B1-A(Runxin) 1 set
Valve fittings, matching(WF) A lot
Quartz Sand: 500kg
1 set
HY
4
Antiscalant dosing device
Metering pump: DMS200(SEKO) 1 set
Medicine box: PE 40L 1
Valve fittings, matching(WF) 1 lot
1 set
HY
5
micron Security filter
Dimension: Φ195×500
Housing:SUS304, PP filter 20 inch 5 pcs
1 set
HY
6
High pressure pump
CDL4-16/3KW
Voltage: 3PH 400V/50Hz
Material: SS304
Accessories: base, regulating valve, check valve, etc.
1 set
CNP
7
SWRO skid
Design temperature:25℃
RO skid frame: SS201
RO membrane(Vontron): ULP32-8040 3 piece
Material:Aromatic polyamide
RO membrane housing
Material: FRP
Spec:8040×1 3 piece
Accessories: flowmeter, pressure gauge, valve pipe, etc.
1 unit
Vontron
HY
8
Piping, valves, bends.
Low pressure parts: UPVC,10 bar(WF)
High pressure parts:UPVC,16 bar(WF)
A lot
WF
9
electrical controller system
Electrical control system
Fully automatic control, automatic(HY) 1set
Circuit breakers, contactors, thermal relays, etc.(CHINT) 1 set
Electrical accessories: national standard
1 set
HY
10
Product tank
Material: PE/SUS304
Capacity: 3m³
Liquid level controller(Lipu) 1
1 set
User prepare
Moreinformation about theROReverse Osmosis System:
Pls contact us:
Email: sales@seawaterroplants.com
www.seawaterroplants.com
Mobile/Whatsapp/Wechat +86 13631738120
Please Attention
HY FACTORY OFFER YOU :
1: FACTORY DIRECT PRICE.
2: NICE QUALITY.
3: ONLINE PAYMENT.
4: SUPPORT REFUND AFTER YOUR INSTALLED THE PLANT IF THERE ARE ANY
PROBLME.
5: AFTER SALES SERVICES 24/7
6. Letters patent
7. ENGINNER CAN BE OVERSEA INSTALLNATION
We have 2 factories +300 workers+ Qualified engineer+ Engineer
Overseas service
2500L/H RO Reverse Osmosis System for garden watering
Process function description
1.RO system use automatic control and semi-control .Pretreatment
parts can adopt fiber glass or stainless steel material.
2.RO system has protected when no power, poor power, larger
electrical current, leakage, short circuit.
3.RO systemwith price is compact, easy installation.
4.RO systemequipped with manual and auto control based on user needed.
5.RO systemwith price produce as per ISO and SGS standard and main parts
accessories have obtained CE certification.
6. All the plants will be commissioning well. Make sure don't have any
problem when arrived site.
7.What we provide not only the good products, but also our whole
team, the quality, experience, and service.
Company Information
Haiyuan workshop
Certifications
Customers photos
Client Comments
Real comments from our client, Trust you will like our products.
Buying Guides
RO system Buying Guides
To find the most appropriate drinking water treatment plantfor your use, please have the following information ready
·Product water flow rate (m3/hr,m3/day,Liter/hr,GPM,GPDetc.)
··Product water purpose(drinking, irrigation, industry process or
others)
·Feed Water TDS(Total dissolved solids).Is it fromBorehole/salt/brackish/lake water
·Iron
·Manganese
·TSS(Total Suspended Solid)
·SDI(Silting Density Index)<3
·Water must be free from oils and grease
·Chlorine must be removed
·Power(110/220/380V/415V/460V,50 or60 Hz)3 phase.
· It is necessary to make water analysis reprot for borehole
water,lake water, seawater.
· If soure water is tap water no need end to us TDS or water
analysis report.
