Model

HY-10m3 PH

Remark

Product Capacity

10m3/hr

Power supply

3PH x 380V, 50-60Hz

Feed water pump

Q=25m3/h

CNP/CHINA

Sand filter

Φ750XH1800mm

FRP

Activated carbon filter

Φ750XH1800mm

FRP

Cation exchange filter

Φ750XH1800mm

FRP

Anion exchange filter

Φ750XH1800mm

FRP

Resin trap

Φ230XH810mm

SUS304

Nos.

Items

Information

1. Pre-treatment part

1.1

Source water tank

Store source water and let water have a sedimentation before entering plant.

1.2

Feed water pump

Provide power for pretreatment & RO system.

Optional brand: CNP, Grundfos. SUS material.

1.3

Sand filter

Different size of quartz sand will be put in the sand filter.

Remove turbidity, SS matter, organic matter, colloid, etc.

1.4

Active carbon filter

Remove color, free chloride, organic matter, harmful matter, etc.

Protect and prolong the life of RO membrane.

1.5

Water softener

Reduce water hardness.

1.6

Control heads

RX-Series, full auto control.

1.7

Pipeline&fittings

UPVC.

2. RO main body part

2.1

PP filter

Prevent large particles, iron, dust, SS matter, impurity into RO membrane.

Protect and prolong working life of RO system.

2.2

High pressure pump

Provide power for RO system.

Provide power for RO system, equipped with over-heat protect, pressure controller.

2.3

RO system

Removes: lead, cooper, barium, chromium, mercury, sodium,

cadmium, fluoride, nitrite, nitrate, and selenium.

2.4

Skid

SUS.

3. Ion exchange system

3.1

PP filter

Remove tiny impurities in water.

3.2

Booster pump

Provide power for ion exchange.

3.3

Ion exchange resin

Further remove ions in water. Purolite from UK.

3.4

Skid

SUS

4. Control system

4.1

Control panel

SUS/A3 carbon painted.

4.2

PLC mode

Mistubishi/Siemens. Working process writen indise.

4.3

Touch screen

WeiNview/Siemens. Full auto control, easy to operate.

4.4

Components

Omron/Schneider. High quality, long working life.
