Iron remove filter sand filter coal filter for sewage treatment
plants
Haiyuan water treatment team supply deferrization filters charcoal filter solution for Belarus.
Please check below client met question and we solution for deferrization filters charcoalfilter.
Customers from Belarus need to deal with iron and other impurities
in treated waste water. and it needs advanced treatment before
entering ultrafiltration and reverse osmosis unit. Because
ultrafiltration and reverse osmosis equipment have higher
requirements on the quality of influent water.
Below is client requirement and waste water parameter:
Can you pick us up sand+coal filters for the metallurgical
industry? I enclose the values in the wastewater that
Place of Origin
CN;GUA
Brand Name
JISHUI
Model Number
HY seawater desalination
Type
sea water desalination
After-sales service provided
Engineers site service
Feed TDS
<35000 PPM
Living pure water TDS
<600 PPM
Recovery efficiency
40%~55%
Control method
Full control or Semi control
warranty
1-3 years
Booster pump
CNP/Grundfos
Size
Customized by client's order
Name
Sea water desalination
pH - 5.9-7.4
Total dissolved solids (TDS) - about 13100 mg/dm3
Suspended solids - 205.7 mg/dm3
Chloride ion (Cl-) - 700-800 mg/dm3
Sulfate ion (SO₄²-) - 1650-2750 mg/dm3
Total iron (Fe)- 3.5-135
These are the values for two days of observation of wastewater.
20m3/hour of wastewater.
Needed with the function of washing by time and pressure (with
manometers), also need two pumps - one for supply, the second for
backwashing (will be carried out by hot water)
According to our experience, the difference between 3mg and 150mg
of iron content in sewage after treatment is too large. There are
two possibilities. One is that the process of iron treatment in
sewage treatment is unstable, and the other is that there is an
error in analysis. Because they only measured the water quality at
intervals of two days with a difference of 50 times.
Iron remove filter sand filter coal filter as for ultrafiltraion
and reverse osmosis pretreatment filter.
After we discuss more detail we supplied below solution(Black is
client. Blue is us)
Do I understand correctly, if iron content will be up to 3 mg/L -
in that case will need 2 filters - sand and carbon, if iron content
will be 6 mg/L - will need more? 3 or 4 filters?
----- if iron content will be up to 3 mg/L and 6mg/L. Both of them
need 2 pcs iron remove filter(site need one tank, add air into the
tank,means aerator, meanwhile add two iron removal filters) . and
also need the sand filter, coal filter. total 4 filters.
If 3mg/L iron means 4-5 days wash media. if 6mg/L iron maybe 2-3
days wash media.
When reduce wash medial then can help use reduce the clean water.
Haiyuan water treatment can supply professional total water
solution for each user. The right designs here waiting for you. Provide solution with our sincerity and technology. Take" quality first, Service first" as our culture. To be friends, to be partners. Each plant can be test in factory for three days before dispatch. Business scope: Reverse osmosis(RO) water treatment plant/system Deionized water treatment plant for industrial Ultrafiltration (UF) water purification plant/system Water softener/ Demineralized Water Treatment Plant Underground water Iron/manganese removal system River/surface water treatment system Seawater water desalination system EDI deionized /Demineralized water treatment plant Intergrated domestic Sewage treatment plant Recycle water treatment plant for waster reuse
Q: Install and commissioning questions.
A: 1st. All the plants will be commissioning and running well for 3
days then delivery. Installation video, photos, operating manual
will send to client with the plants.
2nd. Clinet can come to factory for training how to installation
and maintenance.
3rd. Some main parts will be guaranty two years.
4th .Engineer can go to overseas for installation and
commissioning.
Q: How to control quality?
A: 1. Our company has passed ISO9001:2008 and SGS certification and
all manufacture processes are conducted by the standard strictly.
2. All products adopt RO system simulation software design.
3. All auxiliary parts adopt international and Chinese famous brand
products.
4. Before delivery time ,all complete sets will test run for 3 days
continuously After quality inspection, they can be transferred to
the customers
FAQ
FAQ:
Install and commissioning questions.
1st. All the plants will be commissioning and running well for 3 days
then delivery. Installation video, photos, operating manual will
send to client with the plants.
2nd. Clinet can come to factory for training how to installation and
maintenance.
3rd. Some main parts will be guaranty two years.
4th. Engineer can go to overseas for installation and commissioning.
How to control quality?
1. Our company has passed ISO9001:2008 and SGS certification and
all manufacture processes are conducted by the standard strictly.
2. All products adopt RO system simulation software design.
3. All auxiliary parts adopt international and Chinese famous brand
products.
4. Before delivery time ,all complete sets will test run for 3 days
continuously After quality inspection, they can be transferred to
the customers
5. We have obtained many patents certification from government.
